具有使能功能的 200mA、低 IQ、高精度、低压降稳压器 4-DSBGA -40 to 125
PMIC - 稳压器 - 线性 正 固定 1 输出 200mA 4-DSBGA
立创商城:
LP5990TM-1.8/NOPB
德州仪器TI:
200-mA, low-IQ, high-accuracy low-dropout voltage regulator with enable
得捷:
IC REG LINEAR 1.8V 200MA 4DSBGA
贸泽:
LDO Voltage Regulators Micropower 200mA Low Dropout Voltage Regulator 4-DSBGA -40 to 125
艾睿:
Never worry about components seeing unstable voltages again by implementing this LDO LP5990TM-1.8/NOPB linear regulator manufactured by Texas Instruments. Its typical dropout voltage at current is 0.16@200mA V. It has an overall accuracy of ±1 %. This voltage regulation device&s;s single output can produce a current up to 0.2 A. Supply your circuit with sufficient power by implementing this, which requires a minimum input voltage of 2.2 V that does not exceed 5.5 V. With a fixed output that has a voltage of 1.8 V, this is power management at its best. Maintain a constant voltage level with a load regulation of 5mVTyp and line regulation of 1mVTyp. In order to guarantee safe delivery and allow for quick mounting of this component after delivery, it will be enclosed in tape and reel packaging during shipment. Its polarity is positive. This voltage regulation device has an operating temperature range of -40 °C to 85 °C.
安富利:
LDO Regulator Pos 1.8V 0.2A 4-Pin uSMD T/R
Chip1Stop:
LDO Regulator Pos 1.8V 0.2A 4-Pin DSBGA T/R
Verical:
LDO Regulator Pos 1.8V 0.2A 4-Pin DSBGA T/R
DeviceMart:
IC REG LDO 1.8V .2A 4-USMD
输出接口数 1
输出电压 1.8 V
输出电流 200 mA
静态电流 30.0 µA
输出电容类型 Ceramic
跌落电压 0.16V @200mA
调节输出数 1
输入电压Max 5.5 V
输入电压Min 2.2 V
输出电流Max 0.2 A
工作温度Max 125 ℃
工作温度Min 40 ℃
精度 ±1 %
输入电压 2.2V ~ 5.5V
安装方式 Surface Mount
引脚数 4
封装 WFBGA-4
封装 WFBGA-4
工作温度 -40℃ ~ 85℃
产品生命周期 Active
包装方式 Tape & Reel TR
RoHS标准 RoHS Compliant
含铅标准 Lead Free
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
LP5990TM-1.8/NOPB TI 德州仪器 | 当前型号 | 当前型号 |
LP5990TMX-1.8/NOPB 德州仪器 | 类似代替 | LP5990TM-1.8/NOPB和LP5990TMX-1.8/NOPB的区别 |
