LD29080DT18R

LDO（低压降）线性稳压器，STMicroelectronics，800mA 至 1A### LDO（低压降）线性电压调节器，STMicroelectronics低压降或 LDO 为线性电压稳压器。 我们有多种系列的线性稳压器。 LDO 稳压器可在输入 - 输出差分电压较小时运行。 LDO 电压稳压器可提供快速瞬态响应、宽输入电压范围、低静态电流、低噪声、高 PSRR。

LDO（低压降）线性稳压器，STMicroelectronics，800mA 至 1A

得捷:
IC REG LINEAR 1.8V 800MA DPAK

立创商城:
800mA固定和可调输出极低压降稳压器

欧时:
STMicroelectronics LD29080DT18R LDO 稳压器, 1.8 V输出, 800mA最大输出, ±1%精确度, 2.5 → 13 V输入

艾睿:
This LDO LD29080DT18R linear regulator from STMicroelectronics acts like a variable resistor to maintain a steady voltage level. It has an overall accuracy of ±1 %. Its typical dropout voltage at current is 0.1@150mA|0.2@400mA|0.4@800mA V. This voltage regulation device&s;s single output can produce a current up to 0.8 A. It only needs a voltage of at least 2.5 V while not exceeding 13 V to effectively power your circuit. With a fixed output that has a voltage of 1.8 V, this is power management at its best. Maintain a constant voltage level with a load regulation of 1% and line regulation of 0.5%. This component will be shipped in tape and reel packaging for effective mounting and safe delivery. Its polarity is positive. This voltage regulation device has an operating temperature range of -40 °C to 125 °C. The maximum dropout voltage is 0.7@800mA V.

安富利:
LDO Regulator Pos 1.8V 0.8A 3-Pin2+Tab DPAK T/R
