LM5023MM-2/NOPB

TEXAS INSTRUMENTS  LM5023MM-2/NOPB  控制器, 电流模式控制器, PWM, 14V-8V电源, 130 kHz, VSSOP-8

The is a quasi-resonant Pulse Width Modulated PWM Controller contains all of the features needed to implement a highly efficient off-line power supply. It uses the transformer auxiliary winding for demagnetization detection to ensure critical conduction mode CrCM operation. It features a hiccup mode for overcurrent protection with an auto restart to reduce the stress on the power components during an overload. A skip-cycle mode reduces power consumption at light loads for energy conservation applications ENERGY STAR®, CEPCP and so forth. It also uses the transformer auxiliary winding for output overvoltage protection OVP; if an OVP fault is detected the LM5023 latches off the controller.

.

Critical conduction mode

.

Peak-current mode control

.

Skip-cycle mode for low-standby power

.

Hiccup mode for continuous overload protection

.

Cycle-by-cycle overcurrent protection maintains

.

Accuracy over the universal AC line

.

Line-voltage feed forward

.

OVP Protection by sensing the auxiliary winding

.

Direct opto-coupler interface

.

Leading edge blanking of current sense signal

.

Programmable soft-start

.

Thermal shutdown

.

Green product and no Sb/Br

Device has limited built-in ESD protection, leads should be shorted together or the device placed in conductive foam during storage or handling to prevent electrostatic damage to the MOS gates.
