LP2951CSDX-3.3/NOPB

LP2950 -N / LP2951 -N系列的可调微功耗电压调节器 LP2950-N/LP2951-N Series of Adjustable Micropower Voltage Regulators

This LDO linear regulator developed by Texas Instruments keeps the power stable! Its typical dropout voltage at current is 0.05@100uA|0.38@100mA V. It has an overall accuracy of ±0.5Typ %. This voltage regulation device"s single output can produce a current up to 0.1 A. This will operate at a maximum voltage of 30 V, making it easy to control the power in your circuit. With a fixed output that has a voltage of 3.3 V, this is power management at its best. Maintain a constant voltage level with a load regulation of 0.2% and line regulation of 0.2%. In order to ensure safe delivery and enable quick mounting of this component after delivery, it will be encased in tape and reel packaging during shipment. Its polarity is positive. This voltage regulation device has a minimum operating temperature of -40 °C and a maximum of 125 °C. The maximum dropout voltage is 0.08@100uA|0.45@100mA V.
