LP3996SD-0833/NOPB

低压差稳压器 Dual Linear Regulator with 300mA and 150mA Outputs and Power-On-Reset 10-WSON -40 to 85

PMIC - 稳压器 - 线性 正 固定 2 输出 150mA，300mA 10-WSON（3x3）

得捷:
IC REG LINEAR 0.8V/3.3V 10WSON

立创商城:
LP3996SD-0833/NOPB

德州仪器TI:
150-mA, low-IQ, dual-channel low-dropout voltage regulator with power good & enable

贸泽:
低压差稳压器 Dual Linear Regulator with 300mA and 150mA Outputs and Power-On-Reset 10-WSON -40 to 85

艾睿:
This LDO LP3996SD-0833/NOPB linear regulator from Texas Instruments acts like a variable resistor to maintain a steady voltage level. It has an overall accuracy of ±2.75 %. Its typical dropout voltage at current is 0.11@150mA|0.21@300mA V. This voltage regulation device&s;s 2 outputs can produce a current up to 0.15Min|0.3Min A. The best way to provide power to your application is by using this, which needs a voltage of at least 2 V and no higher than 6 V. With a fixed output that has a voltage of 0.8|3.3 V, this is power management at its best. This component will be shipped in tape and reel packaging to allow for effective mounting and safe delivery. The maximum dropout voltage is 0.22@150mA|0.55@300mA V. Its polarity is positive. This voltage regulation device has an operating temperature range of -40 °C to 85 °C.

安富利:
LDO Regulator Pos 0.8V3.3V 0.15A/0.3A 10-Pin LLP EP T/R

Newark:
# TEXAS INSTRUMENTS  LP3996SD-0833/NOPB  LDO VOLTAGE REGULATOR, 3.3V, 0.3A, LLP-10, FULL REEL
