LDO(低压降)线性电压调节器,STMicroelectronics,2.5A 及以上### LDO(低压降)线性电压调节器,STMicroelectronics低压降或 LDO 为线性电压稳压器。 我们有多种系列的线性稳压器。 LDO 稳压器可在输入 - 输出差分电压较小时运行。 LDO 电压稳压器可提供快速瞬态响应、宽输入电压范围、低静态电流、低噪声、高 PSRR。
LDO(低压降)线性稳压器,STMicroelectronics,2.5A 及以上
得捷:
IC REG LINEAR 3.3V 3A D2PAK-3
欧时:
### LDO(低压降)线性稳压器,STMicroelectronics,2.5A 及以上### LDO(低压降)线性电压调节器,STMicroelectronics低压降或 LDO 为线性电压稳压器。 我们有多种系列的线性稳压器。 LDO 稳压器可在输入 - 输出差分电压较小时运行。 LDO 电压稳压器可提供快速瞬态响应、宽输入电压范围、低静态电流、低噪声、高 PSRR。
立创商城:
LD1085D2M33R
贸泽:
LDO Voltage Regulators 3.3V 3.0A Positive
e络盟:
固定LDO稳压器, 6.3V至30V, 1.3V压降, 3.3V/3A输出, TO-263AA-3
艾睿:
Maintain a steady voltage level with this LDO LD1085D2M33R linear regulator from STMicroelectronics. Its typical dropout voltage at current is 1.3@3A V. It has an overall accuracy of ±1 %. This voltage regulation device&s;s single output can produce a current up to 3 A. By working with a maximum input voltage of 30 V, this is the best way to control the power in your circuit. With a fixed output that has a voltage of 3.3 V, this is power management at its best. A load regulation of 15mV and line regulation of 6mV is necessary for providing a constant voltage level at your output. This product will be shipped in tape and reel packaging so that components can be mounted effectively. This voltage regulation device has an operating temperature range of -40 °C to 125 °C. Its polarity is positive. The maximum dropout voltage is 1.5@3A V.
安富利:
LDO Regulator Pos 3.3V 3A 4-Pin3+Tab D2PAK/A T/R
Chip1Stop:
LDO Regulator Pos 3.3V 3A Automotive 4-Pin3+Tab D2PAK/A T/R
Verical:
LDO Regulator Pos 3.3V 3A 4-Pin3+Tab D2PAK/A T/R
DeviceMart:
IC REG LDO 3.3V 3A D2PAK/A
Win Source:
Linear Voltage Regulator IC Positive Fixed 1 Output 3.3V 3A D2PAK-3
输出接口数 1
输入电压DC 30.0V max
输出电压 3.3 V
输出电流 3 A
针脚数 3
静态电流 10 mA
跌落电压 1.3V @3A
输入电压Max 30 V
输入电压Min 6.3 V
输出电流Max 3 A
工作温度Max 125 ℃
工作温度Min -40 ℃
精度 ±1 %
输入电压 ≤30 V
安装方式 Surface Mount
引脚数 4
封装 TO-263-4
长度 10.4 mm
宽度 9.35 mm
高度 4.6 mm
封装 TO-263-4
工作温度 -40℃ ~ 125℃
产品生命周期 Active
包装方式 Tape & Reel TR
RoHS标准 RoHS Compliant
含铅标准 Lead Free
ECCN代码 EAR99
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
LD1085D2M33R ST Microelectronics 意法半导体 | 当前型号 | 当前型号 |
NCP1117DT50G 安森美 | 功能相似 | LD1085D2M33R和NCP1117DT50G的区别 |
LM1085ISX-3.3/NOPB 德州仪器 | 功能相似 | LD1085D2M33R和LM1085ISX-3.3/NOPB的区别 |
LM3480IM3-3.3/NOPB 德州仪器 | 功能相似 | LD1085D2M33R和LM3480IM3-3.3/NOPB的区别 |
