LM3524DMX/NOPB

40V、0.2A 350KHz PWM 控制器 16-SOIC 0 to 125

降压，升压 稳压器 正或负 输出 升压，降压 - DC DC 切换控制器 IC 16-SOIC

得捷:
IC REG CTRLR BUCK/BOOST 16SOIC

立创商城:
降压型 升压型 8V~40V

德州仪器TI:
40V, 0.2A 350KHz PWM controller

艾睿:
Are you in search of a pulse-width modulation controller? Look no further than Texas Instruments&s; LM3524DMX/NOPB voltage mode PWM controller. With an output that has a voltage of 60 V, this is power management at its best. This voltage mode driver supports boost|buck|flyback|push-pull topology. Its 2 PWM outputs produce a current of 200Max mA. You can operate this at a switching frequency of 350Typ kHz. This product will be shipped in tape and reel packaging so that components can be mounted effectively. This voltage mode driver has an operating temperature range of 0 °C to 125 °C. This device has a maximum of 40 V. This voltage mode driver&s;s maximum duty cycle is 49Typ %.

安富利:
Voltage Mode PWM Controller 60V 200mA 16-Pin SOIC N T/R

Chip1Stop:
Voltage Mode PWM Controller 60V 200mA 16-Pin SOIC T/R

Verical:
Voltage Mode PWM Controller 60V 200mA 350kHz 16-Pin SOIC T/R

DeviceMart:
IC REG BUCK BST FLYBK 5V 16-SOIC

Win Source:
Buck, Boost Regulator Positive or Negative Output Step-Up, Step-Down DC-DC Controller IC 16-SOIC
