LP2985A-10DBVT

TEXAS INSTRUMENTS  LP2985A-10DBVT  固定电压稳压器, LDO, 2.2V至16V, 280mV压差, 10V输出, 150mA输出, SOT-23-5

PMIC - 稳压器 - 线性 正 固定 1 输出 150mA SOT-23-5

立创商城:
LP2985A-10DBVT

德州仪器TI:
150-mA, 16-V, low-dropout voltage regulator with high-accuracy

得捷:
IC REG LINEAR 10V 150MA SOT23-5

e络盟:
固定电压稳压器, LDO, 2.2V至16V, 280mV压差, 10V输出, 150mA输出, SOT-23-5

艾睿:
This LDO LP2985A-10DBVT linear regulator from Texas Instruments is used to manipulate the voltage level of your circuit. It has an overall accuracy of ±1 %. Its typical dropout voltage at current is 0.001@0A|0.007@1mA|0.04@10mA|0.12@50mA|0.28@150mA V. This voltage regulation device&s;s single output can produce a current up to 0.15 A. This will operate at a minimum voltage of 2.2 V and a maximum voltage of 16 V, making it easy to control the power in your circuit. With a fixed output that has a voltage of 10 V, this is power management at its best. Users like the line regulation of 0.014%/V. This component will be shipped in tape and reel packaging for effective mounting and safe delivery. Its polarity is positive. This voltage regulation device has an operating temperature range of -40 °C to 125 °C. The maximum dropout voltage is 0.003@0A|0.01@1mA|0.06@10mA|0.15@50mA|0.35@150mA V.

安富利:
LDO Regulator Pos 10V 0.15A 5-Pin SOT-23 T/R

Chip1Stop:
Single Channel LDO 150-mA Low-Noise, Low-Dropout Regulator With Shutdown LDO Regulator Pos 10V 0.15A 5-Pin SOT-23 T/R

Verical:
LDO Regulator Pos 10V 0.15A 5-Pin SOT-23 T/R

Newark:
# TEXAS INSTRUMENTS  LP2985A-10DBVT  Fixed LDO Voltage Regulator, 2.2V to 16V, 280mV Dropout, 10Vout, 150mAout, SOT-23-5

DeviceMart:
IC REG LDO 10V .15A SOT23-5
