LM337IMP/NOPB

TEXAS INSTRUMENTS  LM337IMP/NOPB.  芯片, 可调负稳压器, -1.2V至-37V, SOT223-3, 整卷

LM337 线性稳压器，Texas Instruments

**Texas Instruments LM337** 可调负电压稳压器在 –1.2 V 到 –37 V 输出电压范围内提供 1.5A 电流额定值（LM337L 型号为 100mA）。 线性稳压器仅需两个外部电阻器即可调节输出电压，且需要一个电容器，用于频率补偿。

.

*LM317** 1.5 A，**LM317L** 0.1 A

波纹抑制 77 dB 到 80 dB（典型）

### 线性稳压器，Texas Instruments

Texas Instruments 固定和可调线性稳压器系列。 该系列包括正极和负极设备，输出电流额定值从 100mA 到 5A。

立创商城:
LM337IMP/NOPB

得捷:
IC REG LIN NEG ADJ 1.5A SOT223-4

欧时:
Texas Instruments LM337 系列 LM337IMP 负电压 线性稳压器, -4.2 → -40 V输入, -1.2 → -37 V输出

德州仪器TI:
1.5-A, negative, adjustable linear voltage regulator

艾睿:
Stable voltages are always needed for sensitive systems implement this standard LM337IMP/NOPB linear regulator from Texas Instruments. This device has a maximum power dissipation of 2000 mW. This voltage regulation device&s;s single output can produce a current up to 1 A. By only needing an input voltage of -4.2 V with a maximum of -50 V, this is the best way to control the power in your circuit. With an adjustable output that has a voltage of -1.2 to -37 V, this is power management at its best. A load regulation of 1% and line regulation of 0.04%/V is necessary for providing a constant voltage level at your output. Its maximum power dissipation is 2000 mW. In order to guarantee safe delivery and allow for quick mounting of this component after delivery, it will be enclosed in tape and reel packaging during shipment. Its polarity is negative. This voltage regulation device has a minimum operating temperature of -40 °C and a maximum of 125 °C.

安富利:
Standard Regulator Neg -1.2V to -37V 1A 4-Pin3+Tab SOT-223 T/R

Chip1Stop:
Standard Regulator Neg -1.2V to -37V 1A 4-Pin3+Tab SOT-223 T/R

Verical:
Standard Regulator Neg -1.2V to -37V 1A 4-Pin3+Tab SOT-223 T/R

Newark:
Linear Voltage Regulator, Adjustable, -50V to -4.2V input, -1.2V to -37V/1A out, SOT-223-4

DeviceMart:
IC REG LDO NEG ADJ 1A SOT223
