低压差稳压器 A 926-2992AIM52.5/NOPB
PMIC - 稳压器 - 线性 正 固定 1 输出 250mA SOT-23-5
立创商城:
LP2992AIM5X-2.5/NOPB
德州仪器TI:
250-mA, 16-V, low-dropout voltage regulator with enable
得捷:
IC REG LINEAR 2.5V 250MA SOT23-5
贸泽:
低压差稳压器
艾睿:
Use this LDO LP2992AIM5X-2.5/NOPB linear regulator from Texas Instruments to vary your voltage levels to your desired level. Its typical dropout voltage at current is 0.005@1mA|0.1@50mA|0.26@150mA|0.45@250mA V. It has an overall accuracy of ±3.5 %. This voltage regulation device&s;s single output can produce a current up to 0.25 A. Supply your circuit with sufficient power by implementing this, which requires a minimum input voltage of 2.2 V that does not exceed 16 V. With a fixed output that has a voltage of 2.5 V, this is power management at its best. Your circuit has the capability to produce a constant current at its output by using a line regulation of 0.014%/V. In order to guarantee safe delivery and allow for quick mounting of this component after delivery, it will be enclosed in tape and reel packaging during shipment. This voltage regulation device has a minimum operating temperature of -40 °C and a maximum of 125 °C. The maximum dropout voltage is 0.009@1mA|0.125@50mA|0.325@150mA|0.575@250mA V. Its polarity is positive.
安富利:
LDO Regulator Pos 2.5V 0.25A 5-Pin SOT-23 T/R
Verical:
LDO Regulator Pos 2.5V 0.25A 5-Pin SOT-23 T/R
Win Source:
Linear Voltage Regulator IC Positive Fixed 1 Output 2.5V 250mA SOT-23-5
输出接口数 1
输出电压 2.5 V
输出电流 250 mA
静态电流 0.065 mA
输出电容类型 Ceramic
跌落电压 0.45V @250mA
调节输出数 1
输入电压Max 16 V
输入电压Min 2.2 V
输出电流Max 0.25 A
工作温度Max 125 ℃
工作温度Min -40 ℃
精度 ±3.5 %
输入电压 ≤16 V
安装方式 Surface Mount
引脚数 5
封装 SOT-23-5
封装 SOT-23-5
工作温度 -40℃ ~ 125℃
产品生命周期 Active
包装方式 Tape & Reel TR
RoHS标准 RoHS Compliant
含铅标准 Lead Free
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
LP2992AIM5X-2.5/NOPB TI 德州仪器 | 当前型号 | 当前型号 |
LP2992AIM5-2.5 德州仪器 | 类似代替 | LP2992AIM5X-2.5/NOPB和LP2992AIM5-2.5的区别 |
LP2992AIM5X-2.5 德州仪器 | 类似代替 | LP2992AIM5X-2.5/NOPB和LP2992AIM5X-2.5的区别 |
