LP38693SD-2.5/NOPB

具有使能功能的 500mA、10V、低压降稳压器 6-WSON -40 to 125

PMIC - 稳压器 - 线性 正 固定 1 输出 500mA 6-WSON（3x3）

得捷:
IC REG LINEAR 2.5V 500MA 6WSON

立创商城:
LP38693SD-2.5/NOPB

德州仪器TI:
500-mA, 10-V, low-dropout voltage regulator with enable

艾睿:
Never worry about components seeing unstable voltages again by implementing this LDO LP38693SD-2.5/NOPB linear regulator manufactured by Texas Instruments. It has an overall accuracy of ±2 %. Its typical dropout voltage at current is 0.08@100mA|0.43@500mA V. This voltage regulation device&s;s single output can produce a current up to 0.5 A. This will operate at a minimum voltage of 2.7 V and a maximum voltage of 10 V, making it easy to control the power in your circuit. With a fixed output that has a voltage of 2.5 V, this is power management at its best. A load regulation of 1.8%/ATyp and line regulation of 0.03%/VTyp is necessary for providing a constant voltage level at your output. This product will be shipped in tape and reel packaging to allow for quick mounting and safe delivery. Its polarity is positive. This voltage regulation device has an operating temperature range of -40 °C to 125 °C. The maximum dropout voltage is 0.145@0.1A|0.725@0.5A V.

安富利:
LDO Regulator Pos 2.5V 0.5A 6-Pin LLP EP T/R

Chip1Stop:
LDO Regulator Pos 2.5V 0.5A 6-Pin WSON EP T/R

Verical:
LDO Regulator Pos 2.5V 0.5A 6-Pin WSON EP T/R

罗切斯特:
LDO Regulator Pos 2.5V 0.5A 6-Pin WSON EP T/R

DeviceMart:
IC REG LDO 2.5V .5A 6LLP
