LM2937ET-10/NOPB

TEXAS INSTRUMENTS  LM2937ET-10/NOPB  固定电压稳压器, LDO, 0V至26V, 500mV压差, 10V输出, 500mA输出, TO-220-3

The is a 10V fixed output low-dropout LDO Linear Regulator capable of supplying up to 500mA of load current. The use of a PNP power transistor provides a low-dropout LDO voltage characteristic. With a load current of 500mA the minimum input to output voltage differential required for the output to remain in regulation is typically 0.5V. Special circuitry has been incorporated to minimize the quiescent current to typically only 10mA with a full 500mA load current when the input to output voltage differential is greater than 3V. The device requires an output bypass capacitor for stability. As with most low-dropout LDO regulators, the ESR of this capacitor remains a critical design parameter, but the device includes special compensation circuitry that relaxes ESR requirements. The device is stable for all ESR below 3R. This allows the use of low ESR chip capacitors.

.

Output trimmed for 5% tolerance under all operating conditions

.

Internal short circuit and thermal overload protection

.

Reverse battery protection

.

60V Input transient protection

.

Mirror image insertion protection

.

Green product and no Sb/Br
