高频 1A 降压直流/直流转换器 6-WSON -40 to 125
降压 开关稳压器 IC 正 可调式 0.6V 1 输出 1A 6-WDFN 裸露焊盘
立创商城:
降压型 Vin=3V~5.5V Vout=600mV~4.5V 1A
德州仪器TI:
High frequency 1 A step-down DC/DC converter
得捷:
LM2830 HIGH FREQUENCY 1 A STEP-D
艾睿:
Adjust the voltage level of your devices with this step down LM2830ZSD/NOPB DC to DC converter from Texas Instruments. This converter&s;s single output can produce a current up to 1 A. Supply your circuit with sufficient power by implementing this, which requires a minimum input voltage of 3 V that does not exceed 5.5 V. With an adjustable output that has a voltage of 0.6 to 4.5 V, this is power management at its best. This converter is 93 % efficient. At a line regulation of 0.02%/VTyp a constant current can be produced at the output of your circuit. You can operate this at a switching frequency of 3000Typ kHz. This product will be shipped in tape and reel packaging so that components can be mounted effectively. This converter has a minimum operating temperature of -40 °C and a maximum of 125 °C.
Chip1Stop:
Conv DC-DC Single Step Down 3V to 5.5V 6-Pin WSON EP T/R
Verical:
Conv DC-DC 3V to 5.5V Step Down Single-Out 0.6V to 4.5V 1A 6-Pin WSON EP T/R
DeviceMart:
IC REG BUCK ADJ 1A 6-LLP
电源电压DC 5.50V max
输出接口数 1
输出电压 0.6V ~ 4.5V
输出电流 1 A
静态电流 3.30 mA
调节输出数 1
开关频率 3 MHz
拓扑结构 Buck
输入电压Max 5.5 V
输入电压Min 3 V
输出电压Max 4.5 V
输出电压Min 0.6 V
输出电流Max 1 A
工作温度Max 125 ℃
工作温度Min -40 ℃
输入电压 3V ~ 5.5V
安装方式 Surface Mount
引脚数 6
封装 WDFN-6
封装 WDFN-6
工作温度 -40℃ ~ 125℃ TJ
产品生命周期 Active
包装方式 Tape & Reel TR
RoHS标准 RoHS Compliant
含铅标准 Lead Free
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
LM2830ZSD/NOPB TI 德州仪器 | 当前型号 | 当前型号 |
LM2830ZSDX/NOPB 德州仪器 | 完全替代 | LM2830ZSD/NOPB和LM2830ZSDX/NOPB的区别 |
LM2830ZSD 德州仪器 | 完全替代 | LM2830ZSD/NOPB和LM2830ZSD的区别 |
