具有 4V UVLO、专用输入接地和关断输入的 5A/3A 双通道栅极驱动器 10-WSON -40 to 125
Think of Texas Instruments" power driver the next time you are in need of a tool that can power your gates on and off. This device has a maximum propagation delay time of 40 ns. This component will be shipped in tape and reel packaging for effective mounting and safe delivery. This gate driver has an operating temperature range of -40 °C to 125 °C. This device has a minimum operating supply voltage of 3.5 V and a maximum of 14 V.
上升/下降时间 14ns, 12ns
输出接口数 2
静态电流 1.00 mA
上升时间 25 ns
下降时间 25 ns
下降时间Max 25 ns
上升时间Max 25 ns
工作温度Max 125 ℃
工作温度Min -40 ℃
电源电压 3.5V ~ 14V
安装方式 Surface Mount
引脚数 10
封装 WDFN-10
封装 WDFN-10
工作温度 -40℃ ~ 125℃ TJ
产品生命周期 Active
包装方式 Tape & Reel TR
RoHS标准 RoHS Compliant
含铅标准 Lead Free
ECCN代码 EAR99
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
LM5110-3SDX/NOPB TI 德州仪器 | 当前型号 | 当前型号 |
LM5110-3SDX 德州仪器 | 完全替代 | LM5110-3SDX/NOPB和LM5110-3SDX的区别 |
LM5110-3SD 德州仪器 | 类似代替 | LM5110-3SDX/NOPB和LM5110-3SD的区别 |
