TEXAS INSTRUMENTS LP3878MRX-ADJ/NOPB 芯片, 稳压器, LDO, 可调, 0.8A, 1V 至 5.5V, SOIC-8 新
The LP3878-ADJ is an 800-mA, adjustable output, voltage regulator designed to provide high performance and low noise in applications requiring output voltages as low as 1 V.
Using an optimized VIP Vertically Integrated PNP process, the LP3878-ADJ delivers superior performance:
得捷:
LP3878-ADJ MICROPOWER 800MA LOW
立创商城:
正 Vin=16V Vout=1V~5.5V 800mA 60dB@1kHz
德州仪器TI:
800-mA, 16-V, adjustable low-dropout voltage regulator with enable
贸泽:
低压差稳压器 LOW NOISE SUB- BANDGAP PSOP 8 LD
e络盟:
LDO Voltage Regulator, Adjustable, 2.5 V to 16 V in, 475 mV drop, 1 V to 5.5 V/0.8A out, SOIC-8
艾睿:
LDO Regulator Pos 1V to 5.5V 0.8A 8-Pin HSOIC EP T/R
安富利:
LDO Regulator Pos 1V to 5.5V 0.8A 8-Pin PSOP EP T/R
Verical:
LDO Regulator Pos 1V to 5.5V 0.8A 8-Pin HSOIC EP T/R
Newark:
# TEXAS INSTRUMENTS LP3878MRX-ADJ/NOPB LDO, ADJ, 0.8A, 1V TO 5.5V, SOIC-8
DeviceMart:
IC REG LDO ADJ .8A 8PSOP
Win Source:
Linear Voltage Regulator IC Positive Adjustable 1 Output 1 V ~ 5.5 V 800mA 8-SO PowerPad
输出接口数 1
输出电压 1V ~ 5.5V
输出电流 800 mA
供电电流 1.5mA ~ 15mA
针脚数 8
静态电流 5.5 mA
输出电容类型 Ceramic
跌落电压 475 mV
调节输出数 1
输入电压Max 16 V
输入电压Min 2.5 V
输出电压Max 5.5 V
输出电压Min 1 V
输出电流Max 0.8 A
工作温度Max 125 ℃
工作温度Min -40 ℃
精度 ±1 %
输入电压 2.5V ~ 16V
安装方式 Surface Mount
引脚数 8
封装 PSOP-EP-8
封装 PSOP-EP-8
工作温度 -40℃ ~ 125℃
产品生命周期 Active
包装方式 Tape & Reel TR
RoHS标准 RoHS Compliant
含铅标准 Lead Free
REACH SVHC版本 2015/06/15
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
LP3878MRX-ADJ/NOPB TI 德州仪器 | 当前型号 | 当前型号 |
LP3878MR-ADJ/NOPB 德州仪器 | 类似代替 | LP3878MRX-ADJ/NOPB和LP3878MR-ADJ/NOPB的区别 |
LP3878MR-ADJ 德州仪器 | 类似代替 | LP3878MRX-ADJ/NOPB和LP3878MR-ADJ的区别 |
LP3878MRX-ADJ 德州仪器 | 类似代替 | LP3878MRX-ADJ/NOPB和LP3878MRX-ADJ的区别 |
