LDO(低压降)线性稳压器,最大 100mA,3.0V 至 3.9V,Texas Instruments### LDO(低压降)线性稳压器,Texas Instruments低压降或 LDO 为线性电压稳压器。 我们有多种系列的线性稳压器。 LDO 稳压器可在输入 - 输出差分电压较小时运行。 LDO 电压稳压器可提供快速瞬态响应、宽输入电压范围、低静态电流、低噪声、高 PSRR。
LDO(低压降)线性稳压器,最大 100mA,3.0V 至 3.9V,Texas Instruments
### LDO(低压降)线性稳压器,Texas Instruments
低压降或 LDO 为线性电压稳压器。 我们有多种系列的线性稳压器。 LDO 稳压器可在输入 - 输出差分电压较小时运行。 LDO 电压稳压器可提供快速瞬态响应、宽输入电压范围、低静态电流、低噪声、高 PSRR。
得捷:
IC REG LINEAR 3.3V 50MA 8SOIC
欧时:
### LDO(低压降)线性电压调节器,最大 100mA,3.0V 至 3.9V,Texas Instruments### LDO(低压降)线性电压调节器,Texas Instruments低压降或 LDO 为线性电压稳压器。 我们有多种系列的线性稳压器。 LDO 稳压器可在输入 - 输出差分电压较小时运行。 LDO 电压稳压器可提供快速瞬态响应、宽输入电压范围、低静态电流、低噪声、高 PSRR。
立创商城:
LM2936M-3.3/NOPB
德州仪器TI:
50-mA, 60-V, low-IQ, low-dropout voltage regulator with reverse voltage protection
贸泽:
低压差稳压器 ULTRA-LOW QUIES CRNT LDO VLTG REG
e络盟:
固定电压稳压器, LDO, 5.5V至40V, 200mV压差, 3.3V输出, 50mA输出, SOIC-8
艾睿:
Say goodbye to unstable voltages with this LDO LM2936M-3.3/NOPB linear regulator from Texas Instruments. It has an overall accuracy of ±2 %. Its typical dropout voltage at current is 0.05@100uA|0.2@50mA V. This voltage regulation device&s;s single output can produce a current up to 0.05 A. Using the part will provide the power your application needs by requiring a voltage only of 4 V and not exceeding a voltage of 40 V. With a fixed output that has a voltage of 3.3 V, this is power management at its best. Operate at a constant current by utilizing the load regulation of 30mV and line regulation of 30mV. In order to ensure parts aren&s;t damaged by bulk packaging, this product comes in tube packaging to add a little more protection by storing the loose parts in an outer tube. The maximum dropout voltage is 0.1@100uA|0.4@50mA V. Its polarity is positive. This voltage regulation device has an operating temperature range of -40 °C to 125 °C.
Jameco:
OPB
Chip1Stop:
LDO Regulator Pos 3.3V 0.05A 8-Pin SOIC Rail
Verical:
LDO Regulator Pos 3.3V 0.05A Automotive 8-Pin SOIC Tube
Newark:
# TEXAS INSTRUMENTS LM2936M-3.3/NOPB Fixed LDO Voltage Regulator, 5.5V to 40V, 200mV Dropout, 3.3Vout, 50mAout, SOIC-8
DeviceMart:
IC REG LDO 3.3V 50MA 8SOIC
Win Source:
Linear Voltage Regulator IC Positive Fixed 1 Output 3.3V 50mA 8-SOIC
电源电压DC 60.0V max
额定电流 50.0 mA
输出接口数 1
输入电压DC 60.0V max
输出电压 3.3 V
输出电流 50 mA
针脚数 8
静态电流 16.0 µA
跌落电压 200 mV
调节输出数 1
输入电压Max 40 V
输入电压Min 5.5 V
输出电流Max 50 mA
工作温度Max 125 ℃
工作温度Min -40 ℃
精度 ±2 %
输入电压 5.5V ~ 40V
安装方式 Surface Mount
引脚数 8
封装 SOIC-8
长度 4.9 mm
宽度 3.9 mm
高度 1.45 mm
封装 SOIC-8
工作温度 -40℃ ~ 125℃
产品生命周期 Active
包装方式 Tube
制造应用 车用, 工业, 电源管理, 自动化与过程控制
RoHS标准 RoHS Compliant
含铅标准 Lead Free
REACH SVHC标准 No SVHC
REACH SVHC版本 2015/06/15
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
LM2936M-3.3/NOPB TI 德州仪器 | 当前型号 | 当前型号 |
LM2936BM-3.3/NOPB 德州仪器 | 完全替代 | LM2936M-3.3/NOPB和LM2936BM-3.3/NOPB的区别 |
LM2936HVBMA-3.3/NOPB 德州仪器 | 完全替代 | LM2936M-3.3/NOPB和LM2936HVBMA-3.3/NOPB的区别 |
LM9036M-3.3/NOPB 德州仪器 | 类似代替 | LM2936M-3.3/NOPB和LM9036M-3.3/NOPB的区别 |
