LM2936MMX-3.3/NOPB

具有反向电压保护功能的 50mA、60V、低 IQ、低压降稳压器 8-VSSOP -40 to 125

PMIC - 稳压器 - 线性 正 固定 1 输出 50mA 8-VSSOP

得捷:
IC REG LINEAR 3.3V 50MA 8VSSOP

立创商城:
LM2936MMX-3.3/NOPB

德州仪器TI:
50-mA, 60-V, low-IQ, low-dropout voltage regulator with reverse voltage protection

艾睿:
Stable power is ideal for better processing this LDO LM2936MMX-3.3/NOPB linear regulator developed by Texas Instruments will help do so. Its typical dropout voltage at current is 0.05@100uA|0.2@50mA V. It has an overall accuracy of ±2 %. This voltage regulation device&s;s single output can produce a current up to 0.05 A. Using the part will provide the power your application needs by requiring a voltage only of 4 V and not exceeding a voltage of 40 V. With a fixed output that has a voltage of 3.3 V, this is power management at its best. At a load regulation of 30mV and line regulation of 30mV your circuit is capable of maintaining a constant voltage level at your output. Tape and reel packaging will encase the product during shipment, ensuring safe delivery and enabling quick mounting of components. The maximum dropout voltage is 0.1@100uA|0.4@50mA V. This voltage regulation device has an operating temperature range of -40 °C to 125 °C. Its polarity is positive.

安富利:
LDO Regulator Pos 3.3V 0.05A 8-Pin MSOP T/R
