TEXAS INSTRUMENTS LM2936M-5.0 固定电压稳压器, LDO, 5.5V至40V, 200mV压差, 5V输出, 50mA输出, SOIC-8
This LDO linear regulator from Texas Instruments acts like a variable resistor to maintain a steady voltage level. It has an overall accuracy of ±2 %. Its typical dropout voltage at current is 0.05@100uA|0.2@50mA V. This voltage regulation device"s single output can produce a current up to 0.05 A. It only needs a voltage of at least 4 V while not exceeding 40 V to effectively power your circuit. With a fixed output that has a voltage of 5 V, this is power management at its best. By operating at a load regulation of 30mV and line regulation of 30mV you can provide a constant voltage at your output. In order to ensure parts aren"t damaged by bulk packaging, this product comes in tube packaging to add a little more protection by storing the loose parts in an outer tube. The maximum dropout voltage is 0.1@100uA|0.4@50mA V. Its polarity is positive. This voltage regulation device has a minimum operating temperature of -40 °C and a maximum of 125 °C.
电源电压DC 60.0V max
输出接口数 1
输出电压 5 V
输出电流 50 mA
供电电流 9µA ~ 2.5mA
针脚数 8
静态电流 9.00 µA
跌落电压 200 mV
调节输出数 1
输入电压Max 40 V
输入电压Min 4 V
输出电压Min 5 V
输出电流Max 0.05 A
工作温度Max 125 ℃
工作温度Min -40 ℃
精度 ±2 %
输入电压 ≤40 V
安装方式 Surface Mount
引脚数 8
封装 SOIC-8
封装 SOIC-8
工作温度 -40℃ ~ 125℃
产品生命周期 Active
包装方式 Tube
RoHS标准 Non-Compliant
含铅标准 Contains Lead
REACH SVHC标准 No SVHC
REACH SVHC版本 2015/06/15
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
LM2936M-5.0 TI 德州仪器 | 当前型号 | 当前型号 |
LM2936M-5.0/NOPB 德州仪器 | 完全替代 | LM2936M-5.0和LM2936M-5.0/NOPB的区别 |
LM2936BM-5.0/NOPB 德州仪器 | 完全替代 | LM2936M-5.0和LM2936BM-5.0/NOPB的区别 |
LM2936MX-5.0/NOPB 德州仪器 | 类似代替 | LM2936M-5.0和LM2936MX-5.0/NOPB的区别 |
