LP2966IMM-3325/NOPB

LDO（低压降）线性电压调节器，双输出，Texas Instruments

LDO（低压降）线性稳压器，双输出，Texas Instruments

立创商城:
LP2966IMM-3325/NOPB

德州仪器TI:
150-mA, dual-channel adjustable low-dropout voltage regulator with power good

得捷:
IC REG LDO 3.3V/2.5V 0.15A 8MSOP

欧时:
### LDO（低压降）线性稳压器，双输出，Texas Instruments### LDO（低压降）线性稳压器，Texas Instruments低压降或 LDO 为线性电压稳压器。 我们有多种系列的线性稳压器。 LDO 稳压器可在输入 - 输出差分电压较小时运行。 LDO 电压稳压器可提供快速瞬态响应、宽输入电压范围、低静态电流、低噪声、高 PSRR。

贸泽:
低压差稳压器 Dual 150Ma Ultra-LDO Reg

艾睿:
Use the LDO LP2966IMM-3325/NOPB linear regulator from Texas Instruments to maintain a constant output voltage. Its typical dropout voltage at current is 0.0009@1mA|0.09@100mA|0.135@150mA V. It has an overall accuracy of ±1.5 %. This voltage regulation device&s;s 2 outputs can produce a current up to 0.15|0.15 A. The best way to provide power to your application is by using this, which needs a voltage of at least 2.7 V and no higher than 7 V. With a fixed output that has a voltage of 2.5|3.3 V, this is power management at its best. Maintain a constant voltage level with a load regulation of 0.1mV/mATyp and line regulation of 0.1mV/VTyp. In order to ensure safe delivery and enable quick mounting of this component after delivery, it will be encased in tape and reel packaging during shipment. The maximum dropout voltage is 0.002@1mA|0.13@100mA|0.195@150mA V. This voltage regulation device has a minimum operating temperature of -40 °C and a maximum of 125 °C. Its polarity is positive.

Chip1Stop:
LDO Regulator Pos 3.3V2.5V 0.15A/0.15A 8-Pin VSSOP T/R

Verical:
LDO Regulator Pos 2.5V3.3V 0.15A/0.15A 8-Pin VSSOP T/R

Newark:
# TEXAS INSTRUMENTS  LP2966IMM-3325/NOPB  LDO, DUAL, 0.15A, 3.3/2.5V, VSSOP-8

DeviceMart:
IC REG LDO 3.3V/2.5V .15A 8MSOP
