LM2936DT-3.0/NOPB

LDO（低压降）线性稳压器，最大 100mA，3.0V 至 3.9V，Texas Instruments### LDO（低压降）线性稳压器，Texas Instruments低压降或 LDO 为线性电压稳压器。 我们有多种系列的线性稳压器。 LDO 稳压器可在输入 - 输出差分电压较小时运行。 LDO 电压稳压器可提供快速瞬态响应、宽输入电压范围、低静态电流、低噪声、高 PSRR。

LDO（低压降）线性稳压器，最大 100mA，3.0V 至 3.9V，Texas Instruments

### LDO（低压降）线性稳压器，Texas Instruments

低压降或 LDO 为线性电压稳压器。 我们有多种系列的线性稳压器。 LDO 稳压器可在输入 - 输出差分电压较小时运行。 LDO 电压稳压器可提供快速瞬态响应、宽输入电压范围、低静态电流、低噪声、高 PSRR。

得捷:
IC REG LINEAR 3V 50MA TO252-3

立创商城:
LM2936DT-3.0/NOPB

德州仪器TI:
50-mA, 60-V, low-IQ, low-dropout voltage regulator with reverse voltage protection

欧时:
Texas Instruments LM2936DT-3.0/NOPB LDO 稳压器, 3 V输出, 50mA最大输出, ±2%精确度, 4 → 40 V输入

贸泽:
低压差稳压器 Ultra-Low Quiescent Current LDO Voltage Regulator 3-TO-252 -40 to 125

艾睿:
Don&s;t let unpredictable voltage levels ruin your circuit! Use this LDO LM2936DT-3.0/NOPB linear regulator from Texas Instruments to control your voltage levels! Its typical dropout voltage at current is 0.05@100uA|0.2@50mA V. It has an overall accuracy of ±2 %. This voltage regulation device&s;s single output can produce a current up to 0.05 A. Supply your circuit with sufficient power by implementing this, which requires a minimum input voltage of 4 V that does not exceed 40 V. With a fixed output that has a voltage of 3 V, this is power management at its best. Maintain a constant voltage level with a load regulation of 30mV and line regulation of 30mV. In order to ensure parts aren&s;t damaged by bulk packaging, this product comes in tube packaging to add a little more protection by storing the loose parts in an outer tube. Its polarity is positive. This voltage regulation device has an operating temperature range of -40 °C to 125 °C. The maximum dropout voltage is 0.1@100uA|0.4@50mA V.

Chip1Stop:
LDO Regulator Pos 3V 0.05A 3-Pin2+Tab TO-252 Rail

Verical:
LDO Regulator Pos 3V 0.05A Automotive 3-Pin2+Tab TO-252 Tube

DeviceMart:
IC REG LDO 3V 50MA TO252
