LT3009EDC-5#TRMPBF

低压差稳压器 5V fixed Vout 20mA, 3uA Iq LDO Micropower Regulator

Make a theoretical system actual by providing stable voltages with this LDO linear regulator from . Its typical dropout voltage at current is 0.115@100uA|0.17@1mA|0.25@10mA|0.28@20mA V. It has an overall accuracy of ±2 %. This voltage regulation device"s single output can produce a current up to 0.02 A. It only needs a voltage of at least 1.6 V while not exceeding 20 V to effectively power your circuit. With a fixed output that has a voltage of 5 V, this is power management at its best. To produce a constant current at your output, supply your circuit with a load regulation of 25mV and line regulation of 12.5mV. This component will be shipped in tape and reel packaging to allow for effective mounting and safe delivery. Its polarity is positive. This voltage regulation device has an operating temperature range of -40 °C to 125 °C. The maximum dropout voltage is 0.18@100uA|0.25@1mA|0.31@10mA|0.35@20mA V.
