具有 P 或 N 沟道钳位 FET 和 0.5V CS 阈值的 90V 有源钳位电压模式 PWM 控制器 16-WSON -40 to 125
正激转换器 稳压器 正,可提供隔离 输出 升压/降压 - DC DC 切换控制器 IC 16-WSON(5x5)
立创商城:
升降压型 8V~15V 580kHz
德州仪器TI:
90V active clamp voltage mode PWM controller with P or N-channel clamp FET and 0.5V CS threshold
得捷:
IC REG CTRLR FWRD CONV 16WSON
艾睿:
Does your circuit require a controlled input voltage? Try using Texas Instruments&s; LM5025ASD/NOPB voltage mode PWM controller today. Its 2 PWM outputs produce a current of 3000|1000 mA. This voltage mode driver supports forward topology. This part offers a switching frequency of 220 kHz in order to work properly. This component will be shipped in tape and reel packaging for effective mounting and safe delivery. This voltage mode driver has an operating temperature range of -40 °C to 125 °C. This voltage mode driver&s;s maximum duty cycle is 80 %. This device has a minimum operating supply voltage of 8 V and a maximum of 15 V.
安富利:
Voltage Mode PWM Controller 3A/1A 16-Pin LLP EP T/R
Chip1Stop:
Voltage Mode PWM Controller 3A/1A 16-Pin LLP EP T/R
Verical:
Voltage Mode PWM Controller 3A/1A 16-Pin WSON EP T/R
频率 650 kHz
电源电压DC 90.0V max
输出接口数 2
输入电压DC 13.0 V
上升时间 20 ns
输出功率 300 W
开关频率 220 kHz
占空比 80 %
最大占空比 80 %
下降时间 15 ns
工作温度Max 125 ℃
工作温度Min -40 ℃
电源电压 13V ~ 90V
电源电压Max 90 V
电源电压Min 13 V
输入电压 13 V
安装方式 Surface Mount
引脚数 16
封装 WFDFN-16
高度 0.8 mm
封装 WFDFN-16
工作温度 -40℃ ~ 125℃ TJ
产品生命周期 Active
包装方式 Cut Tape CT
RoHS标准 RoHS Compliant
含铅标准 Lead Free
REACH SVHC标准 No SVHC
REACH SVHC版本 2015/06/15
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
LM5025ASD/NOPB TI 德州仪器 | 当前型号 | 当前型号 |
LM5025ASDX/NOPB 德州仪器 | 类似代替 | LM5025ASD/NOPB和LM5025ASDX/NOPB的区别 |
LM5025ASD 德州仪器 | 类似代替 | LM5025ASD/NOPB和LM5025ASD的区别 |
