低压差稳压器 Ultra-Lo Quiescent Current LDO Vtg Reg
PMIC - 稳压器 - 线性 正 固定 输出 50mA SOT-223-4
立创商城:
LM2936QMP-5.0/NOPB
德州仪器TI:
Automotive 50-mA, off-battery 60-V, low-dropout voltage regulator with reverse voltage protection
得捷:
LM2936Q-Q1 - ULTRA-LOW QUIESCENT
贸泽:
低压差稳压器 Ultra-Lo Quiescent Current LDO Vtg Reg
艾睿:
This LDO LM2936QMP-5.0/NOPB linear regulator developed by Texas Instruments keeps the power stable! Its typical dropout voltage at current is 0.05@100uA|0.2@50mA V. It has an overall accuracy of ±3 %. This voltage regulation device&s;s single output can produce a current up to 0.05 A. The best way to provide power to your application is by using this, which needs a voltage lower than 40 V. With a fixed output that has a voltage of 5 V, this is power management at its best. By operating at a load regulation of 30mV and line regulation of 30mV you can provide a constant voltage at your output. In order to ensure safe delivery and enable quick mounting of this component after delivery, it will be encased in tape and reel packaging during shipment. Its polarity is positive. This voltage regulation device has an operating temperature range of -40 °C to 125 °C. The maximum dropout voltage is 0.1@100uA|0.4@50mA V.
安富利:
LDO Regulator Pos 5V 0.05A 4-Pin SOT-223 T/R
Chip1Stop:
LDO Regulator Pos 5V 0.05A 4-Pin3+Tab SOT-223 T/R
输出接口数 1
输出电压 5 V
输出电流 50 mA
供电电流 9µA ~ 2.5mA
静态电流 15.0 µA
跌落电压 0.2V @50mA
调节输出数 1
输入电压Max 40 V
输入电压Min 5.5 V
输出电压Min 5 V
输出电流Max 0.05 A
工作温度Max 125 ℃
工作温度Min -40 ℃
精度 ±3 %
安装方式 Surface Mount
引脚数 4
封装 SOT-223-4
封装 SOT-223-4
工作温度 -40℃ ~ 125℃
产品生命周期 Active
包装方式 Tape & Reel TR
RoHS标准 RoHS Compliant
含铅标准 Lead Free
ECCN代码 EAR99
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
LM2936QMP-5.0/NOPB TI 德州仪器 | 当前型号 | 当前型号 |
LM2936MP-5.0/NOPB 德州仪器 | 类似代替 | LM2936QMP-5.0/NOPB和LM2936MP-5.0/NOPB的区别 |
LM2936MP-5.0 德州仪器 | 类似代替 | LM2936QMP-5.0/NOPB和LM2936MP-5.0的区别 |
LM2936QMPX-5.0/NOPB 德州仪器 | 类似代替 | LM2936QMP-5.0/NOPB和LM2936QMPX-5.0/NOPB的区别 |
