LDO(低压降)线性电压调节器,最大 100mA,4.0V 至 15V,Texas Instruments### LDO(低压降)线性电压调节器,Texas Instruments低压降或 LDO 为线性电压稳压器。 我们有多种系列的线性稳压器。 LDO 稳压器可在输入 - 输出差分电压较小时运行。 LDO 电压稳压器可提供快速瞬态响应、宽输入电压范围、低静态电流、低噪声、高 PSRR。
LDO(低压降)线性稳压器,最大 100mA,4.0V 至 15V,Texas Instruments
得捷:
IC REG LINEAR 5V 50MA TO92-3
欧时:
### LDO(低压降)线性电压调节器,最大 100mA,4.0V 至 15V,Texas Instruments### LDO(低压降)线性电压调节器,Texas Instruments低压降或 LDO 为线性电压稳压器。 我们有多种系列的线性稳压器。 LDO 稳压器可在输入 - 输出差分电压较小时运行。 LDO 电压稳压器可提供快速瞬态响应、宽输入电压范围、低静态电流、低噪声、高 PSRR。
立创商城:
LM2936Z-5.0/NOPB
德州仪器TI:
50-mA, 60-V, low-IQ, low-dropout voltage regulator with reverse voltage protection
贸泽:
LDO Voltage Regulators ULTRA-LOW QUIES CRNT LDO VLTG REG
e络盟:
固定电压稳压器, LDO, 5.5V至40V, 200mV压差, 5V输出, 50mA输出, TO-92-3
艾睿:
Stable power is ideal for better processing this LDO LM2936Z-5.0/NOPB linear regulator developed by Texas Instruments will help do so. Its typical dropout voltage at current is 0.05@100uA|0.2@50mA V. It has an overall accuracy of ±2 %. This voltage regulation device&s;s single output can produce a current up to 0.05 A. With a small input voltage of 4 V and a max of 40 V, this will supply sufficient power to your circuit. With a fixed output that has a voltage of 5 V, this is power management at its best. Users like the load regulation of 30mV and line regulation of 30mV. This voltage regulation device has an operating temperature range of -40 °C to 125 °C. The maximum dropout voltage is 0.1@100uA|0.4@50mA V. Its polarity is positive.
安富利:
LDO Regulator Pos 5V 0.05A 3-Pin TO-92 Box
Chip1Stop:
LDO Regulator Pos 5V 0.05A Automotive 3-Pin TO-92 Bulk
TME:
Voltage regulator; LDO, fixed; 5V; 0.05A; TO92; THT; Package: bulk
Verical:
LDO Regulator Pos 5V 0.05A Automotive 3-Pin TO-92 Bulk
Newark:
# TEXAS INSTRUMENTS LM2936Z-5.0/NOPB Fixed LDO Voltage Regulator, 5.5V to 40V, 200mV Dropout, 5Vout, 50mAout, TO-92-3
DeviceMart:
IC REG LDO 5V 50MA TO92-3
Win Source:
Linear Voltage Regulator IC Positive Fixed 1 Output 5V 50mA TO-92-3
电源电压DC 60.0V max
输出接口数 1
输入电压DC 60.0V max
输出电压 5 V
输出电流 50 mA
供电电流 9µA ~ 2.5mA
通道数 1
针脚数 3
静态电流 9.00 µA
跌落电压 200 mV
调节输出数 1
输入电压Max 40 V
输入电压Min 4 V
输出电压Min 5 V
输出电流Max 50 mA
工作温度Max 125 ℃
工作温度Min -40 ℃
精度 ±2 %
输入电压 ≤40 V
安装方式 Through Hole
引脚数 3
封装 TO-92-3
长度 5.2 mm
宽度 4.19 mm
高度 5.2 mm
封装 TO-92-3
工作温度 -40℃ ~ 125℃
产品生命周期 Active
包装方式 Bulk
制造应用 车用, 工业自动化控制
RoHS标准 RoHS Compliant
含铅标准 Lead Free
REACH SVHC版本 2015/06/15
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
LM2936Z-5.0/NOPB TI 德州仪器 | 当前型号 | 当前型号 |
LM2936Z-5.0/LFT1 德州仪器 | 类似代替 | LM2936Z-5.0/NOPB和LM2936Z-5.0/LFT1的区别 |
LM2936Z-5.0/LFT3 德州仪器 | 类似代替 | LM2936Z-5.0/NOPB和LM2936Z-5.0/LFT3的区别 |
LM2936Z-5.0/LFT4 德州仪器 | 类似代替 | LM2936Z-5.0/NOPB和LM2936Z-5.0/LFT4的区别 |
