LP2988ILD-3.8/NOPB

具有低噪声和使能功能的 200mA、16V、低压降稳压器 8-WSON -40 to 125

PMIC - 稳压器 - 线性 输出 200mA 8-WSON（4x4）

立创商城:
LP2988ILD-3.8/NOPB

德州仪器TI:
200-mA, 16-V, low-dropout voltage regulator with low-noise & enable

得捷:
IC REG LINEAR 3.8V 200MA 8WSON

艾睿:
This LDO LP2988ILD-3.8/NOPB linear regulator from Texas Instruments acts like a variable resistor to maintain a steady voltage level. It has an overall accuracy of ±1.6 %. Its typical dropout voltage at current is 0.001@0.1mA|0.09@75mA|0.18@200mA V. This voltage regulation device&s;s single output can produce a current up to 0.2 A. The best way to provide power to your application is by using this, which needs a voltage of at least 2.1 V and no higher than 16 V. With a fixed output that has a voltage of 3.8 V, this is power management at its best. Maintain a constant voltage level with a line regulation of 0.014%/V. In order to ensure safe delivery and enable quick mounting of this component after delivery, it will be encased in tape and reel packaging during shipment. This voltage regulation device has a minimum operating temperature of -40 °C and a maximum of 125 °C. The maximum dropout voltage is 0.002@0.1mA|0.12@75mA|0.32@200mA V. Its polarity is positive.

Win Source:
Linear Voltage Regulator IC Positive Fixed 1 Output 3.8V 200mA 8-WSON 4x4
