LP2989IMM-2.8/NOPB

具有电源正常指示和使能功能的 500mA、16V、低压降稳压器 8-VSSOP -40 to 125

PMIC - 稳压器 - 线性 正 固定 1 输出 500mA 8-VSSOP

得捷:
IC REG LINEAR 2.8V 500MA 8VSSOP

立创商城:
LP2989IMM-2.8/NOPB

德州仪器TI:
500-mA, 16-V, low-dropout voltage regulator with power good & enable

艾睿:
This LDO LP2989IMM-2.8/NOPB linear regulator developed by Texas Instruments keeps the power stable! It has an overall accuracy of ±1.25 %. Its typical dropout voltage at current is 0.001@0.1mA|0.15@200mA|0.31@500mA V. This voltage regulation device&s;s single output can produce a current up to 0.5 A. Use this part at voltages between 2.1 V and 16 V. With a fixed output that has a voltage of 2.8 V, this is power management at its best. By operating at a load regulation of 0.4%Typ and line regulation of 0.014%/V you can provide a constant voltage at your output. This component will be shipped in tape and reel packaging to allow for effective mounting and safe delivery. This voltage regulation device has a minimum operating temperature of -40 °C and a maximum of 125 °C. The maximum dropout voltage is 0.003@0.1mA|0.2@200mA|0.425@500mA V. Its polarity is positive.

安富利:
LDO Regulator Pos 2.8V 0.5A 8-Pin MSOP T/R

Chip1Stop:
LDO Regulator Pos 2.8V 0.5A 8-Pin VSSOP T/R

Win Source:
Linear Voltage Regulator IC Positive Fixed 1 Output 2.8V 500mA 8-VSSOP
