TEXAS INSTRUMENTS LM2990T-12 固定电压稳压器, LDO, -26V至300 mV, 600mV压差, -12V输出, 1A输出, TO-220-3
The is a -12V fixed output negative low-dropout LDO Linear Regulator. The device uses circuit design techniques to provide low-dropout LDO and low-quiescent current. The dropout voltage at 1A load current is typically 0.6V and an ensured worst-case maximum of 1V over the entire operating temperature range. The quiescent current is typically 1mA with 1A load current and an input-output voltage differential greater than 3V. A unique circuit design of the internal bias supply limits the quiescent current to only 9mA when the regulator is in the dropout mode VOUT - VIN <=3 V. Output voltage accuracy is ensured to ±5% over load and temperature extremes.
电源电压DC 300mV max
额定电流 1.50 kA
输出接口数 1
输出电压 -12.0 V
输出电流 1 A
通道数 1
针脚数 3
静态电流 5 mA
跌落电压 600 mV
调节输出数 1
输入电压Max 0.3 V
输出电流Max 1 A
工作温度Max 125 ℃
工作温度Min -40 ℃
精度 ±5 %
输入电压 0.3 V
安装方式 Through Hole
引脚数 3
封装 TO-220-3
封装 TO-220-3
工作温度 -40℃ ~ 125℃
产品生命周期 Active
包装方式 Each
RoHS标准 Non-Compliant
含铅标准 Contains Lead
REACH SVHC标准 No SVHC
REACH SVHC版本 2015/06/15
ECCN代码 EAR99
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
LM2990T-12 TI 德州仪器 | 当前型号 | 当前型号 |
LM2990T-12/NOPB 德州仪器 | 完全替代 | LM2990T-12和LM2990T-12/NOPB的区别 |
LM2990S-12 德州仪器 | 功能相似 | LM2990T-12和LM2990S-12的区别 |
