LM26480QSQX-8D/NOPB

LM26480外部可编程双路大电流降压型DC / DC和双路线性稳压器 LM26480 Externally Programmable Dual High-Current Step-Down DC/DC and Dual Linear Regulators

PMIC - 稳压器 - 线性 切换式 4 输出 降压同步（2），线性（LDO）（2） 2MHz 24-WQFN（4x4）

得捷:
IC REG QUAD BUCK/LNR SYNC 24WQFN

立创商城:
LM26480QSQX-8D/NOPB

德州仪器TI:
Externally configurable dual 1.5A step-down DC/DC and dual 300mA linear regulators

贸泽:
Power Management Specialized - PMIC DL Hi-Crnt SD DC/DC & Linear Regs

艾睿:
Adjust the voltage level of your devices with this step down LM26480QSQX-8D/NOPB DC to DC converter from Texas Instruments. This converter&s;s single output can produce a current up to 1.5 A. By only needing an input voltage of 2.8 V with a maximum of 5.5 V, this is the best way to control the power in your circuit. With an adjustable output that has a voltage of 1 to 3.3 V, this is power management at its best. This device has a typical switch current of 2 A. This converter is 96typ % efficient. A load regulation of 0.0013%/mATyp and line regulation of 0.089%/VTyp is necessary for providing a constant voltage level at your output. You can operate this at a switching frequency of 1600 to 2400 kHz. This converter has a minimum operating temperature of -40 °C and a maximum of 85 °C.

安富利:
Power Management Unit 24-Pin WQFN

Chip1Stop:
Conv DC-DC Single Step Down 2.8V to 5.5V 24-Pin WQFN EP

Verical:
Conv DC-DC 2.8V to 5.5V Step Down Single-Out 1V to 3.3V 1.5A 24-Pin WQFN EP
