LP3891EMRX-1.2/NOPB

具有使能功能的 800mA、超低压降稳压器 8-SO PowerPAD -40 to 125

Linear Voltage Regulator IC 1 Output 800mA 8-SO PowerPad

立创商城:
LP3891EMRX-1.2/NOPB

德州仪器TI:
800-mA, ultra-low-dropout voltage regulator with enable

得捷:
IC REG LIN 1.2V 800MA 8SO PWRPAD

艾睿:
Stable power is ideal for better processing this LDO LP3891EMRX-1.2/NOPB linear regulator developed by Texas Instruments will help do so. Its typical dropout voltage at current is 0.115@800mA V. It has an overall accuracy of ±1.5 %. This voltage regulation device&s;s single output can produce a current up to 0.8 A. With a small input voltage of 1.3 V and a max of 5.5 V, this will supply sufficient power to your circuit. With a fixed output that has a voltage of 1.2 V, this is power management at its best. A load regulation of 0.04%/ATyp and line regulation of 0.01%/VTyp is necessary for providing a constant voltage level at your output. This product will be shipped in tape and reel packaging so that components can be mounted effectively. This voltage regulation device has an operating temperature range of -40 °C to 125 °C. The maximum dropout voltage is 0.32@800mA V. Its polarity is positive.

安富利:
LDO Regulator Pos 1.2V 0.8A 8-Pin PSOP EP T/R

Chip1Stop:
LDO Regulator Pos 1.2V 0.8A 8-Pin HSOP EP T/R

Verical:
LDO Regulator Pos 1.2V 0.8A 8-Pin HSOP EP T/R
