LP3891ESX-1.5/NOPB

具有使能功能的 800mA、超低压降稳压器 5-DDPAK/TO-263 -40 to 125

Linear Voltage Regulator IC 1 Output 800mA DDPAK/TO-263-5

得捷:
LP3891 0.8A FAST-RESPONSE ULTRA

立创商城:
LP3891ESX-1.5/NOPB

德州仪器TI:
800-mA, ultra-low-dropout voltage regulator with enable

贸泽:
LDO Voltage Regulators 0.8A Fast-Response Ultra Low Dropout Linear Regulators 5-DDPAK/TO-263 -40 to 125

艾睿:
Having trouble maintaining a steady voltage? This LDO LP3891ESX-1.5/NOPB linear regulator from Texas Instruments will give you control over the voltage levels of your circuit. It has an overall accuracy of ±1.5 %. Its typical dropout voltage at current is 0.1@800mA V. This voltage regulation device&s;s single output can produce a current up to 0.8 A. The best way to provide power to your application is by using this, which needs a voltage of at least 1.6 V and no higher than 5.5 V. With a fixed output that has a voltage of 1.5 V, this is power management at its best. Maintain a constant voltage level with a load regulation of 0.04%/ATyp and line regulation of 0.01%/VTyp. This component will be shipped in tape and reel packaging for effective mounting and safe delivery. The maximum dropout voltage is 0.3@800mA V. This voltage regulation device has an operating temperature range of -40 °C to 125 °C. Its polarity is positive.

安富利:
LDO Regulator Pos 1.5V 0.8A 6-Pin5+Tab TO-263 T/R

Chip1Stop:
LDO Regulator Pos 1.5V 0.8A 6-Pin5+Tab TO-263 T/R

Verical:
LDO Regulator Pos 1.5V 0.8A 6-Pin5+Tab TO-263 T/R
