具有频率同步功能的 4.5V 至 36V、3A 电流模式同步降压稳压器 20-HTSSOP -40 to 125
降压 开关稳压器 IC 正 可调式 0.8V 1 输出 3A 20-PowerTSSOP(0.173",4.40mm 宽)
得捷:
LM20333 4.5-36V, 3A CURRENT MODE
立创商城:
降压型 Vin=4.5V~36V Vout=800mV~32V 3A
德州仪器TI:
4.5-36V, 3A Current Mode Synchronous Buck Regulator with Frequency Synchronization
艾睿:
Adjust the voltage level of your devices with this step down LM20333MHX/NOPB DC to DC converter from Texas Instruments. This converter&s;s single output can produce a current up to 3 A. Use this part at voltages between 4.5 V and 36 V. With an adjustable output that has a voltage of 0.8 to 32 V, this is power management at its best. This converter is 94 % efficient. You can operate this at a switching frequency of 200Typ kHz. In order to ensure safe delivery and enable quick mounting of this component after delivery, it will be encased in tape and reel packaging during shipment. This converter has a minimum operating temperature of -40 °C and a maximum of 125 °C.
安富利:
Conv DC-DC Single Step Down 4.5V to 36V 20-Pin TSSOP EP T/R
Verical:
Conv DC-DC 4.5V to 36V Step Down Single-Out 0.8V to 32V 3A 20-Pin HTSSOP EP T/R
Win Source:
Buck Switching Regulator IC Positive Adjustable 0.8V 1 Output 3A 20-TSSOP 0.173", 4.40mm Width Exposed Pad
输出接口数 1
输出电压 0.8V ~ 32V
输出电流 3 A
静态电流 2.30 mA
调节输出数 1
开关频率 200 kHz
拓扑结构 Buck
输入电压Max 36 V
输入电压Min 4.5 V
输出电压Max 32 V
输出电压Min 0.8 V
输出电流Max 3 A
工作温度Max 125 ℃
工作温度Min -40 ℃
输入电压 4.5V ~ 36V
安装方式 Surface Mount
引脚数 20
封装 HTSSOP-20
封装 HTSSOP-20
工作温度 -40℃ ~ 125℃ TJ
产品生命周期 Active
包装方式 Tape & Reel TR
RoHS标准 RoHS Compliant
含铅标准 Lead Free
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
LM20333MHX/NOPB TI 德州仪器 | 当前型号 | 当前型号 |
LM20333MH/NOPB 德州仪器 | 类似代替 | LM20333MHX/NOPB和LM20333MH/NOPB的区别 |
LM20333MHE/NOPB 德州仪器 | 类似代替 | LM20333MHX/NOPB和LM20333MHE/NOPB的区别 |
LM20333MH 德州仪器 | 类似代替 | LM20333MHX/NOPB和LM20333MH的区别 |
