LT1117CM#PBF

LT1117 - 800mA Low Dropout Positive Regulators Adjustable and Fixed 2.85V,3.3V, 5V

Never worry about components seeing unstable voltages again by implementing this LDO linear regulator manufactured by . It has an overall accuracy of ±1 %. Its typical dropout voltage at current is 1@100mA|1.05@500mA|1.1@800mA V. This voltage regulation device"s single output can produce a current up to 0.8 A. This will operate at a minimum voltage of 2.45 V and a maximum voltage of 15 V, making it easy to control the power in your circuit. With an adjustable output, this is power management at its best. At a load regulation of 0.4% and line regulation of 0.2% a constant current can be produced at the output of your circuit. The maximum dropout voltage is 1.2@100mA|1.25@500mA|1.3@800mA|1.2@800mA|1.15@500mA|1.1@100mA V. This voltage regulation device has an operating temperature range of 0 °C to 125 °C. Its polarity is positive.
