IC VREF SERIES/SHUNT 10V 8DIP
DESCRIPTION
The LT® 1236 is a precision reference that combines ultra low drift and noise with excellent long-term stability and high output accuracy. The reference output will both source and sink up to 10mA and is almost totally immune to input voltage variations. Two voltages are available: 5V and 10V. The 10V version can be used as a shunt regulator two-terminal zener with the same precision characteris tics as the three-terminal connection. Special care has been taken to minimize thermal regulation effects and temperature induced hysteresis.
FEATURE
■ Ultra-Low Drift: 5ppm/°C Max
■ Trimmed to High Accuracy: 0.05% Max
■ Industrial Temperature Range SO Package
■ Operates in Series or Shunt Mode
■ Pin Compatible with AD586, AD587
■ Output Sinks and Sources in Series Mode
■ Very Low Noise < 1ppm P-P0.1Hz to 10Hz
■ 100% Noise Tested
■ > 100dB Ripple Rejection
■ Minimum Input/Output Differential of 1V
APPLICATIONS
■ A/D and D/A Converters
■ Precision Regulators
■ Precision Scales
■ Inertial Navigation Systems
■ Digital Voltmeters
