Conv DC-DC 3.2V to 34V Step Down Single-Out 5V/3.3V 0.06A Micropower Automotive 6Pin TSOT-23 T/R
Adjust the voltage level of your devices with this step down DC to DC converter from . This converter"s single output can produce a current up to 0.06 A. With a small input voltage of 3.2 V and a max of 34 V, this will supply sufficient power to your circuit. With a fixed output that has a voltage of 5|3.3 V, this is power management at its best. At a line regulation of 0.007%/VTyp your circuit is capable of maintaining a constant voltage level at your output. Tape and reel packaging will encase the product during shipment, ensuring safe delivery and enabling quick mounting of components. This converter has an operating temperature range of -40 °C to 85 °C. This device utilizes micropower technology.
输出接口数 1
输出电压 1.25V ~ 28V
输出电流 60 mA
拓扑结构 Buck
输入电压Max 34 V
输入电压Min 3.2 V
输出电压Max 29.92 V
输出电压Min 1.25 V
输出电流Max 0.06 a
工作温度Max 85 ℃
工作温度Min -40 ℃
输入电压 3.2V ~ 34V
安装方式 Surface Mount
引脚数 6
封装 TSOT-23-6
封装 TSOT-23-6
工作温度 0℃ ~ 85℃ TA
产品生命周期 Unknown
包装方式 Tape & Reel TR
RoHS标准 RoHS Compliant
含铅标准 Lead Free
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
LT1934ES6-1#TRMPBF Linear Technology 凌力尔特 | 当前型号 | 当前型号 |
LT1934IS6-1#TRMPBF 凌力尔特 | 类似代替 | LT1934ES6-1#TRMPBF和LT1934IS6-1#TRMPBF的区别 |
LT1934IS6-1#TRM 凌力尔特 | 类似代替 | LT1934ES6-1#TRMPBF和LT1934IS6-1#TRM的区别 |
