完全兼容TL1963A/LM1086/AMS1086/LD1086 高性能1086系列 1.5A LDO 低至 1V 的压差 电压调整率0.015% 热保护 高PSRR 75dB 3端稳压器
Never worry about components seeing unstable voltages again by implementing this LDO linear regulator manufactured by . Its typical dropout voltage at current is 1.3@1.5A V. This device has a maximum power dissipation of 15000 mW. This voltage regulation device"s single output can produce a current up to 1.5 A. Supply your circuit with sufficient power by implementing this, which does not exceed 20 V. With a fixed output that has a voltage of 3.3 V, this is power management at its best. Operate at a constant current by utilizing the load regulation of 15mV and line regulation of 10mV. Its maximum power dissipation is 15000 mW. Tape and reel packaging will encase the product during shipment, ensuring safe delivery and enabling quick mounting of components. The maximum dropout voltage is 1.5@1.5A V. This voltage regulation device has an operating temperature range of 0 °C to 150 °C. Its polarity is positive.
输出接口数 1
输出电压 3.3 V
输出电流 1.5 A
供电电流 10 mA
耗散功率 15000 mW
静态电流 5 mA
跌落电压 1.3V @1.5A
输入电压Max 20 V
输入电压Min 2.55 V
输出电压Min 3.3 V
输出电流Max 1.5 A
工作温度Max 150 ℃
工作温度Min 0 ℃
耗散功率Max 15000 mW
输入电压 ≤20 V
安装方式 Surface Mount
引脚数 4
封装 TO-263-4
高度 4.57 mm
封装 TO-263-4
工作温度 0℃ ~ 125℃
产品生命周期 Unknown
包装方式 Tape & Reel TR
RoHS标准 RoHS Compliant
含铅标准 Lead Free
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
LT1086CM-3.3#TRPBF Linear Technology 凌力尔特 | 当前型号 | 当前型号 |
LT1086CM-3.3#PBF 凌力尔特 | 类似代替 | LT1086CM-3.3#TRPBF和LT1086CM-3.3#PBF的区别 |
MIC29300-5.0WT 微芯 | 功能相似 | LT1086CM-3.3#TRPBF和MIC29300-5.0WT的区别 |
MIC29300-3.3WU 微芯 | 功能相似 | LT1086CM-3.3#TRPBF和MIC29300-3.3WU的区别 |
