LINEAR TECHNOLOGY LT1236CIS8-5#PBF 电压基准, 精密, 系列, 分流, LT1236系列, 5V, NSOIC-8
Even in the event of large power supply variations, this voltage reference power management device from can produce and maintain a precise DC voltage. It has an initial accuracy of 0.1%. With an output that has a voltage of 5 V, this is power management at its best. Use this part at voltages lower than 40 V. At a load regulation of 100ppm/mA and line regulation of 12ppm/V your circuit is capable of maintaining a constant voltage level at your output. This voltage reference circuit supports series topology. This voltage reference circuit has a minimum operating temperature of -40 °C and a maximum of 85 °C. It runs with a maximum temperature coefficient of 15ppm/°C.
容差 ±0.1 %
输入电压DC 7.20V ~ 40.0V
输出电压 5 V
输出电流 10 mA
供电电流 1.5 mA
通道数 1
针脚数 8
静态电流 1.20 mA
输入电压Max 40 V
输出电压Min 5 V
输出电流Max 10 mA
工作温度Max 85 ℃
工作温度Min -40 ℃
精度 ±0.1 %
输入电压 7.2V ~ 40V
安装方式 Surface Mount
引脚数 8
封装 SOIC-8
高度 1.5 mm
封装 SOIC-8
工作温度 -40℃ ~ 85℃ TA
温度系数 ±15 ppm/℃
产品生命周期 Unknown
包装方式 Tube
RoHS标准 RoHS Compliant
含铅标准 Lead Free
REACH SVHC标准 No SVHC
REACH SVHC版本 2015/12/17
ECCN代码 EAR99
| 型号/品牌 | 代替类型 | 替代型号对比 |
|---|---|---|
LT1236CIS8-5#PBF Linear Technology 凌力尔特 | 当前型号 | 当前型号 |
LT1236CCS8-5#PBF 凌力尔特 | 完全替代 | LT1236CIS8-5#PBF和LT1236CCS8-5#PBF的区别 |
LT1236CIS8-5#TRPBF 凌力尔特 | 类似代替 | LT1236CIS8-5#PBF和LT1236CIS8-5#TRPBF的区别 |
LT1236CCS8-5#TR 凌力尔特 | 功能相似 | LT1236CIS8-5#PBF和LT1236CCS8-5#TR的区别 |
