LM5032MTC/NOPB

PWM Pulse Width Modulation Controllers, Texas Instruments

PWM 控制器，1MHz，LM50xx 系列，Texas Instruments

得捷:
IC REG CTRLR FWRD CONV 16TSSOP

立创商城:
LM5032MTC/NOPB

德州仪器TI:
High voltage dual Interleaved current mode controller

欧时:
### PWM 控制器，1MHz，LM50xx 系列，Texas Instruments### PWM Pulse Width Modulation Controllers, Texas Instruments

e络盟:
控制器, PWM, 15V-8V电源, 1 MHz, 300mV/100mA输出, TSSOP-16

艾睿:
With this LM5032MTC/NOPB current controller, developed by Texas Instruments, easily manage varying levels of output voltage entering your circuit. This current mode controller supports forward topology. Its 2 PWM outputs produce a current of 2500 mA. You can operate this at a switching frequency of 600Typ kHz. In order to ensure parts aren&s;t damaged by bulk packaging, this product comes in tube packaging to add a little more protection by storing the loose parts in an outer tube. This current mode controller has an operating temperature range of -40 °C to 125 °C. This device has a minimum operating supply voltage of 13 V and a maximum of 100 V. This current mode controller&s;s maximum duty cycle is 76Typ %.

安富利:
Current Mode PWM Controller 2.5A 16-Pin TSSOP Rail

Chip1Stop:
Current Mode PWM Controller 2.5A 16-Pin TSSOP Rail

Verical:
Current Mode PWM Controller 2.5A 600kHz 16-Pin TSSOP Tube

Newark:
# TEXAS INSTRUMENTS  LM5032MTC/NOPB  PWM CONTROLLER, 15V, TSSOP-16

DeviceMart:
IC REG CTRLR PWM CM 16-TSSOP
