Conv DC-DC 1.5V to 8V Step Up Single-Out 3.3V 1.2A Micropower 8Pin SOIC N Tube
The is a micropower step-up DC/DC Converter ideal for use in small, low voltage, battery-operated systems. The devices operate from a wide input supply range of 1.5 to 8V. It generates regulated outputs of 3.3 and 5V and the adjustable LT1304 can deliver output voltages up to 25V. Quiescent current, 120µA in active mode, decreases to just 10µA in shutdown with the low-battery detector still active. Peak switch current, internally set at 1A, can be reduced by adding a single resistor from the ILIM pin to ground. The high speed operation of the LT1304 allows the use of small, surface-mountable inductors and capacitors.
- .
- Low-battery detector active in shutdown
- .
- Programmable peak current with one resistor
- .
- 120µA Quiescent current in active mode
- .
- 10µA Quiescent current in shutdown
频率 300 kHz
输出接口数 1
输出电压 3.3 V
输出电流 200 mA
针脚数 8
开关频率 300 kHz
输入电压Max 8 V
输入电压Min 1.5 V
输出电压Max 3.3 V
输出电压Min 3.3 V
输出电流Max 1.2 A
工作温度Max 70 ℃
工作温度Min 0 ℃
电源电压 1.5 V
电源电压Max 8 V
电源电压Min 1.5 V
输入电压 1.5V ~ 8V
安装方式 Surface Mount
引脚数 8
封装 SOIC-8
长度 4.9 mm
宽度 3.9 mm
封装 SOIC-8
工作温度 0℃ ~ 70℃ TA
产品生命周期 Unknown
包装方式 Cut Tape CT
制造应用 Computers & Computer Peripherals, Power Management, Portable Devices
RoHS标准 RoHS Compliant
含铅标准 Lead Free
REACH SVHC标准 No SVHC
REACH SVHC版本 2015/12/17
ECCN代码 EAR99
| 型号/品牌 | 代替类型 | 替代型号对比 |
|---|---|---|
LT1304CS8-3.3#PBF Linear Technology 凌力尔特 | 当前型号 | 当前型号 |
LT1304CS8-3.3#TRPBF 凌力尔特 | 类似代替 | LT1304CS8-3.3#PBF和LT1304CS8-3.3#TRPBF的区别 |
