TEXAS INSTRUMENTS LM20136MH 直流-直流开关降压逐步递减稳压器, 可调, 2.95V-5.5V输入, 800mV-5V输出, 6A输出, TSSOP-16
The is a full-featured synchronous Buck Regulator capable of delivering up to 6A of continuous output current. The current-mode control loop can be compensated to be stable with virtually any type of output capacitor. For most cases, compensating the device only requires two external components, providing maximum flexibility and ease of use. The device is optimized to work over the input voltage range of 2.95 to 5.5V making it suitable for a wide variety of low voltage systems. The device features internal overvoltage protection OVP and overcurrent protection OCP circuits for increased system reliability. A precision enable pin and integrated UVLO allows the turn on of the device to be tightly controlled and sequenced. Startup inrush currents are limited by both an internally fixed and externally adjustable soft-start circuit. Fault detection and supply sequencing are possible with the integrated power good circuit.
- .
- Accurate current limit minimizes inductor size
- .
- Frequency synchronization pin
- .
- Starts up into pre-biased loads
- .
- Output voltage tracking
- .
- Peak current mode control
- .
- Adjustable output voltage down to 0.8V
- .
- Adjustable soft-start with external capacitor
- .
- Precision enable pin with hysteresis
- .
- Integrated OVP, UVLO, power good and thermal shutdown
- .
- 97% Peak efficiency
- .
- 16 and 20mR Integrated FET switches
- .
- Green product and no Sb/Br
