Current Mode PWM Controller 1A 500kHz 8Pin SOIC N Tube
has the solution you need for your voltage control needs with their current controller. Its single PWM output produces a current of 1000 mA. It has a switching frequency of 500 kHz. This current mode controller has a minimum operating temperature of -40 °C and a maximum of 100 °C. This current mode controller"s maximum duty cycle is 48Typ %. This device has a maximum of 25 V.
电源电压DC 25.0V max
输出接口数 1
耗散功率 1000 mW
静态电流 170 µA
上升时间 50 ns
开关频率 500kHz MAX
占空比 48 %
最大占空比 48 %
下降时间 30 ns
工作温度Max 100 ℃
工作温度Min -40 ℃
耗散功率Max 1000 mW
电源电压 11V ~ 25V
安装方式 Surface Mount
引脚数 8
封装 SOIC-8
封装 SOIC-8
工作温度 -40℃ ~ 100℃ TJ
产品生命周期 Unknown
包装方式 Tube
RoHS标准 RoHS Compliant
含铅标准 Lead Free
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
LT1244IS8#PBF Linear Technology 凌力尔特 | 当前型号 | 当前型号 |
LT1244IS8#TRPBF 凌力尔特 | 完全替代 | LT1244IS8#PBF和LT1244IS8#TRPBF的区别 |
UC3844N 德州仪器 | 功能相似 | LT1244IS8#PBF和UC3844N的区别 |
UC3843AN 德州仪器 | 功能相似 | LT1244IS8#PBF和UC3843AN的区别 |
