LGN2E331MELZ30

330uF ±20% 250V 1200mA Φ22mm

铝电解器 径向，Can - 卡入式 - 105°C 时为 3000 小时

立创商城:
330uF ±20% 250V

得捷:
CAP ALUM 330UF 20% 250V SNAP

艾睿:
Using the aluminum anode based electrolytic LGN2E331MELZ30 electrolytic capacitor, developed by Nichicon, you can filter out lower signal frequencies. It can withstand a voltage of 250 VDC. This aluminum electrolytic capacitor has a maximum operating temperature of 105 °C. The LGN2E331MELZ30 aluminum electrolytic capacitor has a snap-in termination style. This part has a lead diameter of 0.8 mm and a pitch of 10 mm. It has a tolerance of 20%. This product is 30 mm tall with a diameter of 22 mm. Its leakage current is 860@5Min μA. Its capacitance value is 330uF.

安富利:
Cap Aluminum 330uF 250V 20% 22 X 30mm 10mm 1200mA 2000 hr 105°C Bulk
