LP3873ES-2.5/NOPB

LDO（低压降）线性电压调节器，3A，Texas Instruments### LDO（低压降）线性电压调节器，Texas Instruments低压降或 LDO 为线性电压稳压器。 我们有多种系列的线性稳压器。 LDO 稳压器可在输入 - 输出差分电压较小时运行。 LDO 电压稳压器可提供快速瞬态响应、宽输入电压范围、低静态电流、低噪声、高 PSRR。

Linear Voltage Regulator IC 1 Output 3A DDPAK/TO-263-5

立创商城:
LP3873ES-2.5/NOPB

德州仪器TI:
3-A, low-dropout voltage regulator with power good & enable for 2.5 V & 3.3V

得捷:
IC REG LIN 2.5V 3A DDPAK/TO263-5

欧时:
### LDO（低压降）线性电压调节器，3A，Texas Instruments### LDO（低压降）线性电压调节器，Texas Instruments低压降或 LDO 为线性电压稳压器。 我们有多种系列的线性稳压器。 LDO 稳压器可在输入 - 输出差分电压较小时运行。 LDO 电压稳压器可提供快速瞬态响应、宽输入电压范围、低静态电流、低噪声、高 PSRR。

艾睿:
Maintain a steady voltage level with this LDO LP3873ES-2.5/NOPB linear regulator from Texas Instruments. It has an overall accuracy of ±1.5 %. Its typical dropout voltage at current is 0.08@300mA|0.8@3A V. This voltage regulation device&s;s single output can produce a current up to 3 A. Using the part will provide the power your application needs by requiring a voltage only of 2.5 V and not exceeding a voltage of 7 V. With a fixed output that has a voltage of 2.5 V, this is power management at its best. To produce a constant current at your output, supply your circuit with a load regulation of 0.08%Typ and line regulation of 0.02%Typ. In order to ensure parts aren&s;t damaged by bulk packaging, this product comes in tube packaging to add a little more protection by storing the loose parts in an outer tube. Its polarity is positive. The maximum dropout voltage is 0.1@300mA|1@3A V. This voltage regulation device has a minimum operating temperature of -40 °C and a maximum of 125 °C.

安富利:
LDO Regulator Pos 2.5V 3A 6-Pin5+Tab TO-263 Rail

Newark:
# TEXAS INSTRUMENTS  LP3873ES-2.5/NOPB  Fixed LDO Voltage Regulator, 2.5V to 7V, 800mV Dropout, 2.5Vout, 3Aout, TO-263-5

DeviceMart:
IC REG LDO 2.5V 3A TO263-5
