3.9mF ±20% 50V 2560mA Φ22mm
This electrolytic aluminum capacitor from has an anode consisting of pure aluminum foil and is used to filter lower frequencies. It can withstand a voltage of 50 VDC. This aluminum electrolytic capacitor has a maximum operating temperature of 105 °C. This product is 45 mm tall with a diameter of 22 mm. Its leakage current is 1450@5Min μA. The LGU1H472MELZ aluminum electrolytic capacitor has a snap-in termination style. This part has a lead diameter of 0.8 mm and a pitch of 10 mm. Its capacitance value is 4700uF. It has a tolerance of 20%.
额定电压DC 50.0 V
工作电压 50 VDC
电容 4700 µF
容差 ±20 %
产品系列 LGU
纹波电流 2560 mA
纹波电流高频 2.56A @120Hz
纹波电流低频 2.944A @50kHz
工作温度Max 105 ℃
工作温度Min -40 ℃
额定电压 50 V
安装方式 Through Hole
封装 Snap-In
高度 45 mm
直径 22.0 mm
封装 Snap-In
工作温度 -40℃ ~ 105℃
产品生命周期 Active
包装方式 Bulk
最小包装 50
寿命（小时） 3000 h
制造应用 通用
RoHS标准 RoHS Compliant
含铅标准 Lead Free
REACH SVHC版本 2015/12/17
ECCN代码 EAR99
| 型号/品牌 | 代替类型 | 替代型号对比 |
|---|---|---|
LGU1H472MELZ Nichicon 尼吉康 | 当前型号 | 当前型号 |
B41252A6478M000 爱普科斯 | 类似代替 | LGU1H472MELZ和B41252A6478M000的区别 |
381LX472M050H452 Cornell Dubilier ElectronicsCDE | 功能相似 | LGU1H472MELZ和381LX472M050H452的区别 |
ECOS1HA472BA 松下 | 功能相似 | LGU1H472MELZ和ECOS1HA472BA的区别 |
