LT1129IST-5#TRPBF

LDO Regulator Pos 5V 0.7A 4Pin3+Tab SOT-223 T/R

Never worry about components not turning off and on due to lack of voltage with this LDO linear regulator from . Its typical dropout voltage at current is 0.13@10mA|0.25@100mA|0.37@500mA|0.45@700mA V. This voltage regulation device"s single output can produce a current up to 0.7 A. With a small input voltage of 4.15 V and a max of 30 V, this will supply sufficient power to your circuit. With a fixed output that has a voltage of 5 V, this is power management at its best. At a load regulation of 20mV and line regulation of 10mV a constant current can be produced at the output of your circuit. This product will be shipped in tape and reel packaging for quick mounting and safe delivery. The maximum dropout voltage is 0.2@10mA|0.35@100mA|0.45@500mA|0.55@700mA V. This voltage regulation device has a minimum operating temperature of -40 °C and a maximum of 125 °C. Its polarity is positive.
