LM2678SX-ADJ/NOPB

TEXAS INSTRUMENTS  LM2678SX-ADJ/NOPB  直流-直流开关降压, 逐步递降稳压器, 可调, 8V-40V输入, 1.2V-37V/5A输出, 260kHz, TO-263-7 新

The LM2678 series of regulators are monolithic integrated circuits which provide all of the active functions for a step-down buck switching regulator capable of driving up to 5-A loads with excellent line and load regulation characteristics. High efficiency >90% is obtained through the use of a low ON-resistance DMOS power switch. The series consists of fixed output voltages of 3.3 V, 5 V, and 12 V and an adjustable output version.

The SIMPLE SWITCHER® concept provides for a complete design using a minimum number of external components. A high fixed frequency oscillator 260 kHz allows the use of physically smaller sized components. A family of standard inductors for use with the LM2678 are available from several manufacturers to greatly simplify the design process.

The LM2678 series also has built-in thermal shutdown, current limiting, and an ON/OFF control input that can power down the regulator to a low 50-µA quiescent current standby condition. The output voltage is ensured to a ±2% tolerance. The clock frequency is controlled to within a ±11% tolerance.
