4A 500kHz/1MHz 同步降压稳压器 16-HTSSOP -40 to 85
降压 开关稳压器 IC 正 可调式 0.8V 1 输出 4A 16-PowerTSSOP(0.173",4.40mm 宽)
得捷:
IC REG BUCK ADJ 4A 16HTSSOP
立创商城:
降压型 Vin=2.95V~5.5V Vout=800mV~5V 4A
德州仪器TI:
4A 500 kHz / 1 MHz Synchronous Buck Regulator
艾睿:
Adjust the voltage level of your devices with this step down LM2854MHX-1000/NOPB DC to DC converter from Texas Instruments. This converter&s;s single output can produce a current up to 4 A. Supply your circuit with sufficient power by implementing this, which requires a minimum input voltage of 2.95 V that does not exceed 5.5 V. With an adjustable output that has a voltage of 0.8 to 5 V, this is power management at its best. To produce a constant current at your output, supply your circuit with a load regulation of 0.25mV/ATyp and line regulation of 0.04%Typ. This converter is 98 % efficient. You can operate this at a switching frequency of 1050Typ kHz. Tape and reel packaging will encase the product during shipment, ensuring safe delivery and enabling quick mounting of components. This converter has a minimum operating temperature of -40 °C and a maximum of 85 °C.
安富利:
Conv DC-DC Single Step Down 2.95V to 5.5V 16-Pin TSSOP EP T/R
Verical:
Conv DC-DC 2.95V to 5.5V Synchronous Step Down Single-Out 0.8V to 5V 4A 16-Pin HTSSOP EP T/R
输出接口数 1
输出电压 0.8V ~ 5V
输出电流 4 A
静态电流 1.70 mA
调节输出数 1
开关频率 1.05 MHz
拓扑结构 Buck
输入电压Max 5.5 V
输入电压Min 2.95 V
输出电压Max 5 V
输出电压Min 0.8 V
输出电流Max 4 A
工作温度Max 85 ℃
工作温度Min -40 ℃
输入电压 2.95V ~ 5.5V
安装方式 Surface Mount
引脚数 16
封装 TSSOP-16
封装 TSSOP-16
工作温度 -40℃ ~ 85℃ TA
产品生命周期 Active
包装方式 Tape & Reel TR
RoHS标准 RoHS Compliant
含铅标准 Lead Free
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
LM2854MHX-1000/NOPB TI 德州仪器 | 当前型号 | 当前型号 |
LM2854MH-1000/NOPB 德州仪器 | 类似代替 | LM2854MHX-1000/NOPB和LM2854MH-1000/NOPB的区别 |
