LGN2G271MELC25

270uF ±20% 400V 1220mA Φ35mm

铝电解器 径向，Can - 卡入式 - 105°C 时为 3000 小时

得捷:
CAP ALUM 270UF 20% 400V SNAP

立创商城:
270uF ±20% 400V

艾睿:
The pure aluminum anode on the electrolytic LGN2G271MELC25 electrolytic capacitor, designed from Nichicon, is the solution to your signal filtering needs. It can withstand a voltage of 400 VDC. This aluminum electrolytic capacitor has a maximum operating temperature of 105 °C. It has a tolerance of 20%. Its leakage current is 980@5Min μA. Its capacitance value is 270uF. The LGN2G271MELC25 aluminum electrolytic capacitor has a snap-in termination style. This product is 25 mm tall with a diameter of 35 mm. This part has a lead diameter of 0.8 mm and a pitch of 10 mm.

安富利:
Cap Aluminum 270uF 400V 20% 35 X 25mm 10mm 1220mA 2000 hr 105°C Bulk

Chip1Stop:
Cap Aluminum Lytic 270uF 400V 20% 35 X 25mm Snap-In 10mm 1220mA 2000h 105ÂÂ℃ Bulk

Verical:
Cap Aluminum Lytic 270uF 400V 20% 35 X 25mm Snap-In 10mm 1220mA 3000h 105C Bulk
