LT1634BIS8-2.5#PBF

LINEAR TECHNOLOGY  LT1634BIS8-2.5#PBF  电压基准, 精准微功率, 分流 - 固定, LT1634系列, 2.5V, NSOIC-8

The LT1634 series micropower precision shunt Voltage Reference for use with calibrators. The band-gap reference uses trimmed precision thin film resistors to achieve 0.05% initial voltage accuracy. Improved curvature correction technique guarantees 10ppm/°C maximum temperature drift. Advances in design, processing and packaging techniques guarantee 10µA operation and low temperature cycling hysteresis. The LT1634 does not require an output compensation capacitor, but is stable with capacitive loads. Low dynamic impedance makes the LT1634 reference easy to use from unregulated supplies. The LT1634 reference can be used as a high performance upgrade to the LM185/LM385, LT1004 and LT1034 where lower power and guaranteed temperature drift is required.

.

10µA Low operating current

.

<1R Dynamic impedance
