3.5V 至 60V、500mA 同步降压转换器 16-HTSSOP -40 to 125
Buck Switching Regulator IC Positive Adjustable 1V 1 Output 500mA 16-PowerTSSOP 0.173", 4.40mm Width
得捷:
IC REG BUCK ADJ 500MA 16HTSSOP
立创商城:
降压型 Vin=3.5V~60V Vout=1V~28V 500mA
德州仪器TI:
3.5 - 60V, 500mA Synchronous Step-Down Voltage Converter
艾睿:
Adjust the voltage level of your devices with this step down LM46000PWP DC to DC converter from Texas Instruments. This converter&s;s single output can produce a current up to 0.5 A. By only needing an input voltage of 3.5 V with a maximum of 60 V, this is the best way to control the power in your circuit. With an adjustable output that has a voltage of 1 to 28 V, this is power management at its best. You can operate this at a switching frequency of 200 to 2200 kHz. In order to ensure parts aren&s;t damaged by bulk packaging, this product comes in tube packaging to add a little more protection by storing the loose parts in an outer tube. This converter has an operating temperature range of -40 °C to 125 °C.
安富利:
Conv DC-DC Single Step Down 3.5V to 60V 16-Pin HTSSOP Tube
Verical:
Conv DC-DC 3.5V to 60V Synchronous Step Down Single-Out 1V to 28V 0.5A Automotive 16-Pin HTSSOP EP Tube
Win Source:
IC REG BUCK ADJ 500MA 16HTSSOP / Buck Switching Regulator IC Positive Adjustable 1V 1 Output 500mA 16-PowerTSSOP 0.173", 4.40mm Width
输出接口数 1
输出电压 1V ~ 28V
输出电流 500 mA
静态电流 24.0 µA
调节输出数 1
开关频率 200kHz, 2200kHz
拓扑结构 Buck
输入电压Max 60 V
输入电压Min 3.5 V
输出电压Max 28 V
输出电压Min 1 V
输出电流Max 0.5 A
工作温度Max 125 ℃
工作温度Min -40 ℃
输入电压 60 V
安装方式 Surface Mount
引脚数 16
封装 HTSSOP-16
封装 HTSSOP-16
工作温度 -40℃ ~ 125℃
产品生命周期 Active
包装方式 Rail, Tube
RoHS标准 RoHS Compliant
含铅标准 无铅
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
LM46000PWP TI 德州仪器 | 当前型号 | 当前型号 |
LM46000PWPT 德州仪器 | 类似代替 | LM46000PWP和LM46000PWPT的区别 |
LM46000PWPR 德州仪器 | 类似代替 | LM46000PWP和LM46000PWPR的区别 |
