LP3852ES-1.8/NOPB

低压差稳压器 1.5A Low Dropout LDO

PMIC - 稳压器 - 线性 正 固定 1 输出 1.5A DDPAK/TO-263-5

得捷:
IC REG LIN POS ADJ 1.5A DDPAK

立创商城:
LP3852ES-1.8/NOPB

德州仪器TI:
1.5-A, 7-V, ultra-low-dropout voltage regulator with power good & enable

贸泽:
低压差稳压器 1.5A Low Dropout LDO

艾睿:
Control the voltage level of your circuit with this LDO LP3852ES-1.8/NOPB linear regulator from Texas Instruments. Its typical dropout voltage at current is 0.024@150mA|0.24@1.5A V. It has an overall accuracy of ±1.5 %. This voltage regulation device&s;s single output can produce a current up to 1.5 A. Supply your circuit with sufficient power by implementing this, which requires a minimum input voltage of 2.5 V that does not exceed 7 V. With a fixed output that has a voltage of 1.8 V, this is power management at its best. Your circuit has the capability to produce a constant current at its output by using a load regulation of 0.06%Typ and line regulation of 0.02%Typ. In order to ensure parts aren&s;t damaged by bulk packaging, this product comes in tube packaging to add a little more protection by storing the loose parts in an outer tube. The maximum dropout voltage is 0.035@150mA|0.28@1.5A V. Its polarity is positive. This voltage regulation device has an operating temperature range of -40 °C to 125 °C.

安富利:
LDO Regulator Pos 1.8V 1.5A 6-Pin5+Tab TO-263 Rail

Chip1Stop:
LDO Regulator Pos 1.8V 1.5A 6-Pin5+Tab TO-263 Rail

Verical:
LDO Regulator Pos 1.8V 1.5A 6-Pin5+Tab TO-263 Tube

DeviceMart:
IC REG LDO 1.8V 1.5A TO263-5

Win Source:
Linear Voltage Regulator IC Positive Fixed 1 Output 1.8V 1.5A DDPAK/TO-263-5
